DC+AC Box for Solar PV System
IP65 DC + AC box for the system Solar PV + BESS.
Including over-voltage protection and isolating at solar DC side.
Equips AC breaker ( RCCB or RCBO for options ) and AC surge arrester at AC side.
An isolating plastic plate between DC components and AC components ensure safety operating.
DC Switch
*UL508i approval, IEC60947
*Patented DC arc extinguish chamber
*Magnetic Steels inside ensure rapid and safe extinguishing
DC SPD
*New IEC 61643, UL1449
*Designed for solar PV protection
*Higher capacity In 20KA ( IEC, UL )
*Response time <25ns
Specification | ||
Model Number | BHS-2/2(DC+AC) | |
DC Input | 2 strings | |
DC Output | 2 strings | |
Max Voltage | 600V | 1000V |
Max Current Output | 50A | |
Battery System | 1 string with switch and fuses | |
AC RCCB (RCBO for option) | Type A 40A 300mA | |
AC Breaker 1 | Single Phase For AC load | |
AC Breaker 2 | Single Phase For AC SPD | |
Enclosure | ||
Material | Polycarbonate | |
Degree of Protection | IP65 | |
Impacts | IK10 | |
Dimensions (W*H*D) | 26 modules: 292*370*132mm | |
DC Input / Output | MC4 connectors | |
AC Cable Gland | PG 21 | |
Environment | ||
Operating temperature | -25℃ - +60℃ | |
